CNC Drilling Machine WDC501S1


More information you need?
Contact us now!

Falit Machinery Co.,Ltd.

+86510-88588333-816 linda@falitmac.com Information form

Technician Data

Model WDC501S1
Panel length 250-1500mm
Panel width 60-250mm
Panel thickness 10-25mm
Max drilling speed （X/Y/Z） 64/64/20m/min
Drilling spindle rotating speed 4500rpm
Grooving saw motor 2.2kw
Max. grooving speed (X/Y/Z) 100/30/30m/min
Horizontal drills X：2 * 2 Y：2 * 2
Vertical drills 12
Length pisitioning method Servo
Drilling speed 1.5s/hole
Total power 12kw
Machine size 3155×2750×2195mm
Net weight 3800KG
