Laser edge banding machine FEC758 Laser


Edge banding direction:

Highlights

  • Aluminum honeycomb and wood panel edge banding one button exchange;
  • V-belt pressing: pressing force even, makes the panel moving smoothly, no indentation, keeep the panel surface clean and edge banding quality better.;
  • PC control, 24 inches touch screen computer display;
  • Laser / PUR(EVA optional) glue edge banding exchange;
  • PUR glue machine with 2 color tanks;
  • Pneumatic 7 wheels edge tape pressing device

More information you need?
Contact us now!

Falit Machinery Co.,Ltd.

+86510-88588333-816 linda@falitmac.com Information form

Technician Data

Model

FEC758 Laser

Panel length

≥120mm (corner trimming on ≥200mm)

Panel width

≥80mm

Panel thickness

9-60mm (EVA)

9-50mm (PUR)

Edge tape thickness

0.4-3mm

Feeding speed

9-26m/min

Dust extraction

φ125mm*8

Total power

37.5kw + 12.5kw(PUR)

Min panel size

120*80mm

Machine size

10600×850×1850mm

Machine weight

4700kg
