There are quite a few parts to be adjusted on the edgebanding machine, such as roughing knives, finishing knives, pressure wheels, taper wheels, scrapers, polishing wheels, and so on, which are the parts to be adjusted according to different edgebanding applications. Familiarizing yourself with the points and methods of adjusting each part will make it easier to maintain your edgebanding machine and reduce the burden of operating it daily.
However, many workers responsible for operating edgebanding machines do not know much about adjusting edgebanding machine parts, let alone their adjustment methods. This article will organize the finishing knife, taper wheel, and polishing wheel, which are the three main parts for needy people to popularize.
Finishing Knife
The adjustment of the finishing cutter is similar to that of the roughing cutter in that the finishing cutter has several handles for adjustment. The left and right handles are vertically oriented and are responsible for different adjustments. The handle on the left is used to adjust the work done on the upper R-knife, while the handle on the right is used to change the job done on the lower R-knife.
There is also a handle at the end of the motor; when the handle is turned clockwise, it is a backward cutter so that the edge after sealing is small, while when the handle is turned counterclockwise, it is an inward cutter so that the edge after sealing is larger. In practical application, experienced edge banding machine operators can be skilled in using the handle; you can adjust out of the smooth lines and a more rounded edge banding effect to achieve the best.
Taper wheel
The Taper wheel is divided into the upper taper wheel and lower taper wheel; its strength is according to the motor seat on the chuck screw to adjust. When the taper wheel is turned clockwise, its pressure increases; when the taper wheel is turned counterclockwise, its pressure decreases. However, the pressure to adjust the taper wheel should be moderate. Many novices who operate edgebanding machines commit some operations from time to time, changing the pressure of the tapered wheel to a greater or lesser extent.
Such a mistake in adjustment will certainly impact the performance of the edge banding machine. Suppose the pressure of the taper wheel is adjusted large when sealing the edge of the plate. In that case, the taper wheel seat back resistance will be very large, which will lead to bad trimming, or in more serious cases, it will lead to the edge sealing process of the plate depletion or edge sealing machine failure. If taper wheel pressure is not enough, the taper wheel can not play the role of application, which also leads to trimming the edge.
Polishing wheel
There is a degree of polishing wheel adjustment, according to the experienced workers of edge banding machine manufacturers; generally, the lower surface of the polishing wheel is lower than the upper surface of the plate by three to five millimeters more. Specific details of polishing wheel adjustment are as follows. Firstly, use the six-millimeter Allen wrench to loosen the two M8 screws, and then move the motor in and out by hand to a suitable position for the next operation.
Next, use the fishtail handle to adjust the motor so that when rotated clockwise, the motor moves down and vice versa. After adjusting the motor, tighten the M8 screw. It should be noted that when adjusting here, the motor should not move downward too much. Otherwise, the front end of the plate will easily lose its edges and cause wear and tear, but at the same time, it should not move upward too much. Otherwise, it will affect the polishing effect and the plates quality.
Conclusion
Edge banding machines have been used for a long time. However, there will be performance loss, as long as by certain points and methods, in the day-to-day maintenance and maintenance of the edge banding machine, the adjustment of the components are by the standard or experience to adjust, no doubt you can make the edge banding machine day long always new.
